One component, heat resistant toughened epoxy system passes NASA low outgassing

Key Features

  • High shear and peel strengths
  • Resists severe thermal cycling
  • Serviceable from 4K to 400°F
  • Withstands 1,000 hours 85°C/85% RH

Product Description

Master Bond Supreme 10HTCL features a unique blend of performance properties including both high shear and peel strengths along with convenient handling. This one component system is formulated to cure at elevated temperatures, e.g. 60-75 minutes at 250°F, shorter times can be achieved at higher temperatures. Tensile shear strengths of 2,800-3,000 psi and T-peel strengths of 25-30 pli are readily obtained. Supreme 10HTCL has a number of outstanding processing advantages; no mixing is necessary prior to use, the viscosity remains constant with time (i.e. it will not thicken over time), the working life is unlimited at room temperature, and the material is room temperature storable. It is cryogenically serviceable and has a wide temperature range of 4K to +400°F.

Master Bond Supreme 10HTCL readily withstands severe thermal cycling along with mechanical shock and vibration. It is very resistant to many chemicals including water, oils, fuels, solvents, acids and bases. It has excellent adhesion to metals, glass, ceramics and many plastics. The cured epoxy is a superior electrical insulator. Its natural color is amber, but other colors are available. Supreme 10HTCL has a higher viscosity but flows nicely and can be easily applied to substrates. Supreme 10HTCL’s high performance properties coupled with its convenient handling make it widely used in a variety of applications in the aerospace, electronic, electrical, computer, metalworking, appliance, automotive and chemical industries.

Product Advantages

  • One component system
  • Unlimited working life at room temperature
  • Versatile cure schedules at elevated temperatures
  • Good electrical insulator
  • Resists thermal shock and cycling

Industrial Certifications


ASTM E595 Compliant

1,000 Hours at 85°C/85% RH

Meets EU Directive 2015/863

Packaging


Can

Pail

Syringe

Supreme 10HTCL is available is various sizes and units to accommodate customer's needs.
